National Pipe Organ Register N09762



The Organ specification

  GREAT ORGAN





  CHOIR ORGAN



  Double Diapason

16ft



  Open Diapason

8ft

  Open Diapason No1

8ft



  Vial D'Orchestre

8ft

  Open Diapason No2

8ft



  Dulciana

8ft

  Hohl Flute

8ft



  Claribel Flute

8ft

  Principal

4ft



  Unda Maris

8ft

  Harmonic Flute

4ft



  Wald Flute

4ft

  Fifteenth

2ft



  Clarinet

8ft

  Mixture 12.19.22

3 Ranks



  Tremulan



  Tromba

8ft



  Tromba from No9 Great

8ft











  SWELL ORGAN





PEDAL ORGAN



  Open Diapason

8ft



  Harmonic Bass

32ft

  Lieblich Gedeckt

8ft



  Open Diapason

16ft

  Echo Gamba

8ft



  Violone from No1 Great

16ft

  Voix Celestes

8ft



  Bourdon

16ft

  Gemshorn

4ft



  Dulciana

16ft

  Fifteenth

2ft



  Octave

8ft

  Mixture 17.19.22

3 Ranks



  Bass Flute

8ft

  Double Trumpet

16ft



  Double Trumpet

  from No8 Swell

16ft

  Cornopean

8ft



  Trombone

16ft

  Oboe

8ft



  Tromba from No9 Great

8ft

  Clarion

4ft







  Tremulant









In addition the organ has a full range of couplers, thumb and foot pistons and a detached console.

Each of the above names refers to one rank (set) of pipes with a particular sound eg flute. The length quoted, in feet, refers to the length of the pipe giving the lowest (deepest) note in that particular rank. The pitch of the notes produced by an 8ft rank of pipes is one octave above a 16ft rank, and one octave below a 4ft rank.

For comparison, the set of the notes produced by 8ft ranks of pipes is comparable in pitch to that of a piano. Apart from the length, which fixes the pitch, the tone is determined by the width, design and construction of the particular pipe.
